Weld Connection

Weld

Weld type:

Electrode ultimate tensile strength X_u: MPa

Size (is W_f for flare bevel weld) D: mm

Length X_u: mm

Angle of axis of weld: °

Weld Properties

Weld type: Joint penetration groove

X_u: 490 MPa

D: 6 mm

L: 51 mm

Angle of axis of weld: 0 °

Thickness, t: 10 mm

Specified minimum tensile strength, F_u: 450MPa

Specified minimum yield strength, F_y: 300MPa

Base Metal

Thickness t: mm

Specified minimum tensile strength F_u: MPa

Specified minimum yield strength F_y: MPa

Results

Φ_w = 0.67

A_m = 306 mm²

A_w = 216 mm²

0.67 * Φ_w * A_m * F_u = 61.81 kN

0.67 * Φ_w * A_w * X_u = 47.51 kN

V_r = min (V_rb, V_rw) = 47.51 kN
